PVC INSULATED FLAT 3 CORE SUBMERSIBLE CABLES FROM SIZE 1.5 SQ. MM. TO 50 SQ. MM.
SUBMERSIBLE WIRES ARE MADE USING ETP GRADE COPPER CONDUCTORS WITH 101% CONDUCTIVITY HAVING MORE THAN 99.97% PURITY. THESE COPPER CONDUCTORS ARE FURTHER DRAWN AND ANNEALED TO 110% OF STANDARDS SET UNDER IS 8783:1995 AND IS 694:2010.
PLUO manufactures Submersible Flat Cables with fire retardant, fire resistant, lead-free and non-toxic insulation properties. These cables are manufactured to offer energy savings, durability and endure voltage fluctuations. The PVC insulated and sheathed 3 core-flat cables come with high water resistance, all weather proof, longer flex life and abrasion resistant features.
Features
ROHS Compliant
Anti-Termite & Anti-Rodent
Anti-Termite & Anti-Rodent
Specifications
| Size in mm | R/DD in mm | L/DD in mm | Normal Conductor Resitance at 20oc Ω/KM | copper Elongation % | Appmotor Range HP | (R/OD) Weight Kg/Km | (L/OD) Weight Kg/Km |
|---|---|---|---|---|---|---|---|
| 0.40 | 0.80/40 | 0.70/30 | 136.20 | 26 | 1.00 | 1.476 | 1.335 |
| 0.50 | 0.90/40 | 0.80/30 | 87.46 | 28 | 1.50 | 2.155 | 1.980 |
| 0.60 | 1.00/40 | 0.90/30 | 58.91 | 29 | 2.00 | 2.995 | 2.800 |
| 0.70 | 1.10/40 | 1.00/30 | 44.50 | 29 | 3.00 | 3.958 | 3.821 |
| 0.80 | 1.20/40 | 1.00/30 | 33.91 | 30 | 4.00 | 5.112 | 4.925 |
| 0.90 | 1.30/40 | 1.20/30 | 26.62 | 30 | 5.00 | 6.312 | 6.188 |
| 1.00 | 1.40/40 | 1.30/30 | 21.60 | 32 | 7.50 | 7.697 | 7.570 |
| 1.10 | 1.50/40 | 1.40/30 | 17.63 | 32 | 10.00 | 9.254 | 9.145 |
| 1.20 | 1.60/40 | 1.50/30 | 14.94 | 33 | 12.50 | 10.894 | 10.769 |
| 1.30 | 1.70/40 | 1.60/30 | 12.87 | 33 | 15.00 | 12.702 | 12.578 |
| 1.40 | 1.90/50 | 1.80/40 | 10.95 | 34 | 15.00 | 14.910 | 14.785 |
| 1.50 | 2.00/50 | 1.90/40 | 9.62 | 34 | 20.00 | 17.105 | 16.980 |
| 1.60 | 2.10/50 | 2.00/40 | 8.54 | 35 | 25.00 | 19.250 | 19.124 |
| 1.70 | 2.20/50 | 2.10/40 | 7.20 | 35 | 25.00 | 21.715 | 21.600 |
| 1.80 | 2.30/50 | 2.20/40 | 6.28 | 35 | 30.00 | 24.225 | 24.090 |
| 1.90 | 2.40/50 | ... | 5.76 | 36 | 30.00 | 26.850 | ... |
| 2.00 | 2.50/50 | ... | 5.20 | 36 | 40.00 | 29.644 | ... |
| 2.10 | 2.60/50 | ... | 4.94 | 36 | 50.00 | 32.714 | ... |
| 2.20 | 2.70/50 | ... | 4.50 | 36 | 50.00 | 35.63 | ... |
